HONGPOE DC SE-2000-110, 2000W 110V power supply, 0-5V PWM, PLC analog control of output voltage and current, ON/OFF, N+1

Model: SE-2000-110

Input Voltage: 110VAC/220VAC (Single Voltage Input)
Output Voltage: 110V
Output Current: 0-18A
Power: 2000W
Frequency: 50/60Hz
Dimensions: 280 x 180 x 65 mm
Certifications: CE, KC, EAC, ROHS, LVD, DOE

Details







SE-2000-110 Switching Power Supply

  • DC Output: 110V / 18A(2000W)

  • Control Features:

    1. Output Voltage Adjustment: 0–110V continuously adjustable via external potentiometer

    2. Remote Output Voltage Control: Supports 0–5V/0–10V analog signal, PLC, or PWM signal for 0–110V adjustable output

    3. Output Current Adjustment: 0–18A continuously adjustable via external potentiometer

    4. Remote Output Current Control: Supports 0–5V/0–10V analog signal, PLC, or PWM signal for 0–18A adjustable output

    5. Remote ON/OFF: Built-in ON/OFF control interface

    6. N+1 Parallel Redundancy: Supports multiple units in parallel for redundancy and power expansion
