HONGPOE 85V 2000W switching power supply, 0-5V PWM, PLC analog control of output voltage (0-85V DC) and current (0-23.5A), ON/OFF, can be paralleled, SE-2000-85

Model: SE-2000-85

Input Voltage: 110VAC/220VAC (Single Voltage Input)
Output Voltage: 85V
Output Current: 0-23.5A
Power: 2000W
Frequency: 50/60Hz
Dimensions: 280 x 180 x 65 mm
Certifications: CE, KC, EAC, ROHS, LVD, DOE

Details







SE-2000-85 Switching Power Supply

  • DC Output: 85V / 23.5 (2000W)

  • Control Features:

    1. Output Voltage Adjustment: 0–85V continuously adjustable via external potentiometer

    2. Remote Output Voltage Control: Supports 0–5V/0–10V analog signal, PLC, or PWM signal for 0–85V adjustable output

    3. Output Current Adjustment: 0–23.5A continuously adjustable via external potentiometer

    4. Remote Output Current Control: Supports 0–5V/0–10V analog signal, PLC, or PWM signal for 0–23.5A adjustable output

    5. Remote ON/OFF: Built-in ON/OFF control interface

    6. N+1 Parallel Redundancy: Supports multiple units in parallel for redundancy and power expansion
