HONGPOE MS-1000-110 1000W 110V Adjustable DC Power Supply 0-110V 9A | LED Strip, Motors, 3D Printer, Lab, LiFePO4 Charger

Features:

AC Input: 110VAC or 220VAC, single voltage input
No PFC function
Thermal Control: Built-in temperature-controlled fan, automatically starts/stops based on temperature
Output Voltage Adjustment: 0~100% of rated voltage, continuously adjustable
Output Current Adjustment: 10%~100% of rated current, continuously adjustable
Protections: Short circuit, overload, overvoltage, overtemperature
Certifications: CE, KC, EAC, RoHS, LVD, UKCA, DOE

Details







Model: MS-1000-110 Switching Power Supply

  • DC Output
  • Voltage: 110V
  • Current: 9A
  • Power: 1000W
  • Dimensions: 240 × 125 × 65 mm
  • Weight: 1.45 KG

Control Features

  • Output voltage adjustment: 0–110V continuously adjustable via on‑board potentiometer (502)

  • Output current adjustment: 1-9A continuously adjustable via on‑board potentiometer (502)

Switching Power Supply Characteristics

  • Wide input voltage: Supports AC 100‑132V / 186‑264V (auto/manual switch), compatible with global grids.

  • Multiple protections: Built‑in short circuit, overload, overvoltage, overtemperature protection; auto‑recovery after fault removal.

  • Low ripple & noise: Integrated EMI filter, output ripple ≤200mV, low interference for sensitive equipment.

  • High efficiency: Efficiency ≥85% (up to 91% for high‑end models), low heat generation.

  • Full certifications: CE, EAC, KC, FCC, UKCA, RoHS, LVD, etc.

Main Applications

  • LED lighting (strips, modules, signage, displays)

  • CCTV (cameras, recorders, access controllers)

  • Industrial automation (PLC, sensors, robots, CNC)

  • 3D printing / CNC (heated beds, spindle motors, stepper motors)

  • New energy & charging (on‑board power, chargers, LiFePO₄ battery packs)

  • R&D & labs (adjustable supply for testing, teaching)

  • Communication equipment (base stations, switches, routers)

  • Special equipment (thermoelectric coolers/heaters, air purifiers, electronic fridges)
